Internal Aluminium Doors & Glass Room Dividers

Made-to-measure steel-look internal doors, glazed screens and room dividers, fabricated by Armstrong Industries using the Aluna+ aluminium interior system from Alunet Systems. The standard frame finish is textured black, with RAL colour options available for both the aluminium frames and our in-house coated glass.explore our specialist colour finishing.

​

Slim sightlines. Flexible design.

Steel-look aluminium internal doors without the visual weight

Internal aluminium doors divide a room without closing it off. Slim frames and large areas of glass allow light to move between spaces while creating a clear architectural separation.

Armstrong Industries fabricates the Aluna+ interior system for trade customers. The range combines slim aluminium sections with configurable glazing bars, single or double swing doors, fixed panes and corner arrangements.

It works equally well in contemporary homes, renovation projects, offices and other commercial interiors where a clean steel-look appearance is required.

Aluna+ interior system

Internal door options for a wide range of projects

Coated & Privacy Glass for Internal Aluminium Doors

Coated Glass Options applied inhouse

Our internal aluminium doors can be specified with a range of coated glass finishes, allowing you to control both the level of privacy and the overall appearance of the door.

From completely clear glass through to highly obscured frosted finishes, each option changes the character of the door while still allowing light to pass between rooms.

Clear Glass — 0% opacity
The cleanest and most open option, giving maximum light transmission and visibility. Ideal where the aluminium frame itself is the main architectural feature.

Smoke / Graphite — approximately 25–35% opacity
A contemporary darker finish that works particularly well with black aluminium frames. It adds a degree of privacy while retaining good light transmission and a strong modern appearance.

Bronze Grey — approximately 25–30% opacity
A warmer alternative to conventional grey glass. The subtle bronze tone softens the appearance of the black frame and works particularly well in residential interiors.

Neutral Grey — approximately 35–45% opacity
A balanced option combining privacy with good levels of transmitted light. The neutral colour gives a clean architectural appearance without introducing a strong colour tone.

Frosted White — approximately 65–80% opacity
For areas where privacy is more important, the frosted white finish significantly obscures the view while still allowing natural light through. Ideal for offices, bathrooms, utility spaces and internal room divisions.

​

The level of opacity can be varied to suit the application, allowing installers and designers to balance privacy, light transmission and interior style.

Key product features

  • Slim steel-look aluminium sections non thermally broken

  • Optional  25/25 thumb turn dead lock

  • Single and double swing doors

  • Fixed glazed panes and corner configurations

  • Glazed room dividers up to 2000mm x 2500mm per assembly, subject to specification

  • Assemblies can be coupled for larger glazed divisions

  • 4mm and 6mm glazing compatibility

  • Safety, reeded, frosted, privacy and painted glass options

  • Vertical and horizontal adjustable hinges

  • Clip-in glazing beads

  • Lock-box and kick-plate options

  • Textured black finish standard with RAL colours on request



For trade customers, installers and specifiers, the principal system data is set out below. These figures are taken from the July 2026 Aluna+ Interior technical manual and should be confirmed against the current fabrication specification when ordering.

Specification Aluna+ Interior

System Aluna+ Interior by Alunet Systems, fabricated by Armstrong Industries

Principal material6060 T66 extruded aluminium to BS EN 755-9

Powder coating Black only Qualicoat, 60 micron specification

Outer frame profile 42 x 26 mm

Sash profile 35 x 26 mm

Transom profile 35 x 29 mm

Georgian / glazing bar 27 mm face

Hinged sash sizes 500-1000 mm W x 500-2500 mm H

Fixed pane sizes 300-2000 mm W x 300-2500 mm H

Glazing 4 mm or 6 mm single glazing

Standard painted finishTextured black RAL 9005

Special colours RAL colours available on request painted in house

Manufacturing toleranceOverall assembled height and width ±3 mm at 20 ±5°C

Hinges Three butt hinges per hinged sash

Heritage option Lock-box detail and optional 80 mm kick panel

Hardware options

The current system schedule includes lock-and-latch hardware, finger bolts, ball catches, standard lever handles, knurled and blade lever handles, 150 mm pull handles, escutcheons and thumb-turn cylinder options. Availability depends on the selected door configuration.

 Clear Opening Guide

The Aluna+ technical manual gives simple clear-opening calculations based on the overall frame width W:

Single hinged door: Clear opening = W - 86 mm

Double hinged doors, both leaves open: Clear opening = W - 120 mm

For double doors where the slave leaf remains closed, contact Armstrong with the overall frame width and configuration and we can calculate the available clear opening.

 Glazing & Installation

The Aluna+ system accepts 4 mm or 6 mm single glazing. The supplied July 2026 technical manual specifies safety glazing for API Interior products and references BS 6206, with glazing practice referenced to BS 6262.

The system uses clip-in beads and dedicated glazing platforms. Door glass is toe-and-heeled with glazing packers as required to keep the sash square. Through-frame fixing is identified in the manual, with installation packers positioned adjacent to fixings and spanning the full depth of the profile.

Coated & Privacy Glass for Internal Aluminium Doors

Our internal aluminium doors can be specified with a range of coated glass finishes, allowing the level of privacy and appearance of the door to be tailored to the interior.

Clear Glass - 0% opacity
Maximum light and visibility.

Smoke / Graphite - approximately 25-35% opacity
A darker contemporary finish with increased privacy while retaining good light transmission.

Bronze Grey - approximately 25-30% opacity
A warmer tint that softens the contrast of a black frame.

Neutral Grey - approximately 35-45% opacity
Balanced privacy and light with a neutral architectural appearance.

Frosted White - approximately 65-80% opacity
High privacy while retaining transmitted light.

Publishing note - sliding doors

The July 2026 technical manual contains sliding-door designs, but several sliding-specific profiles and hardware items and the sliding assembly pages are marked COMING SOON. Do not advertise sliding doors as currently available until Armstrong has confirmed release/availability with Alunet Systems.

Specification disclaimer

System specifications can change. Confirm current Alunet/Armstrong fabrication limits, hardware availability and standards at quotation/order stage.

 Aluna+ Interior - Key Technical Specification

internal door

profile chart

Trade enquiries

Need a price for internal aluminium doors?

Send us your sizes, drawings or proposed layout and we can help you specify the right configuration.
